Product Features
*Descaling efficiency up to 92%
*Non-magnetic and requires no power supply
*No chemical additives
*Maintenance-free installation
*Up to 10 years of operational lifespan
Descaling efficiency of up to 92%
Scale buildup is the primary cause of reduced heat transfer efficiency in various heating equipment. The ScaleDp Water Treatment Descaler offers a descaling efficiency of up to 92%, effectively removing stubborn scale from pipes, water heaters, heating elements, and other equipment. This improves the heat transfer efficiency of these devices, thereby extending their operational lifespan.
Chip's element
Special multicomponent alloy is preparedby high temperature melting of 9 kinds(Cu,Zn,Ni and so on) of metals withdifferent electronegativity. By controllingthe composition ratio of various metalsand using special processing technology,columnar crystals (similar to batteries)are formed along the axis of S100 crystalin the alloy.
| Specification | Details |
|---|---|
| Body Material | Stainless Steel 304 (European Standard 1.4301, AISI 304) |
| Pipe Types | Copper, CPVC, PVC, PEX |
| Operating Temperature | Inlet: 0°C to 280°C |
| DPSE Descaling Chip | 9 Alloy |
| Installation Environment | ScaleDp devices can be mounted horizontally or vertically,Ion exchangers, electromagnetic systems, or systems with external power supply should not be installed in systems with ScaleDp devices. |
Specifications and Parameters
| Mode | Nominal Diameter | Connection | Diameter (mm) | Length (mm) | Weight (kg) |
Max Flow (m3/ Hour) |
MinFlow (m3/ Hour) |
Ambient Temp°C |
PressureLevel [LB] |
Preset Pressure/ Pressure Drop (bra] |
| CM001 | DN32 | 11/4" Thread | Φ62 | 320 | 2.5 | 8 | 1.45 | 0-280 | <150 | 10/0.1 |
| CM002 | DN40 |
11/2" Thread |
Ф72 | 420 | 3.9 | 10 | 2.26 | 0-280 | <150 | 10/0.1 |
| CM003 | DN50 |
2" Thread |
Ф100 | 430 | 5.8 | 20 | 3.53 | 0-280 | <150 | 10/0.1 |
Water Quality Requirement
| Hardness | PH | Iron | TDS |
| ≤800mg/L | 3-10 | ＜5mg/L | ≤2000ppm |
why choose our products
Your Best Scale Prevention System .At ScaleDp, our mission is to revolutionize the way industries tackle the persistent challenge of scale buildup. We are driven by a vision of a world where scale-related problems are minimized, leading to improved efficiency, sustainability, and cost savings across various sectors by using DPSE technology powered by ScaleDp.
Product Comparison
| products |
|
|
|
|
| Model number | ScaleDp water descaler | Water Softener | Electronic Descaler | Chemical Descaling |
| Working Principle | Water generates a weak electric current in the DPSE system, converting limescale from calcite to aragonite, which detaches easily from pipes | Ion exchange technology works by replacing calcium (Ca²⁺) and magnesium (Mg²⁺) ions with sodium (Na⁺) ions using salt, thereby preventing scale buildup. | It emits high-frequency or pulsed signals to alter the crystallization of calcium and magnesium ions, preventing them from forming scale on pipes and heating elements. | Chemical descaling uses acids or agents to dissolve scale deposits like calcium and magnesium carbonates into soluble compounds. |
| Descaling Efficiency | 92% | 60% | 75% | 60% |
| Maintenance Requirement | Maintenance-free | Requires regular salt addition. | Ensure constant power supply. | Requires maintenance. |
| Operation Cost | One-time purchase cost. | Costs of electricity and salt replacement. | Power | Chemical purchase. |
| Water Quality lmpact | NO | yes | no | yes |
| Waste Water Discharges | no | yes | no | yes |
Common Questions
Does the effectiveness of ScaleDp® change over time?
No, it won't. ScaleDp®'s DPSE water treatment system is made of an alloy fused from 9 metals, distinct from traditional pure copper or zinc electrodes. The DPSE alloy exhibits exceptional stability and can sustain operation for 10 years.
How is the dislodged scale expelled?
After detachment, the solidified scale appears in block or granule form in the water flow, necessitating prompt cleaning of the filter and clearing of the water outlet.
What is the lifespan of ScaleDp®?
Under stable water quality and usage conditions without external damage, ScaleDp® has a lifespan of 10 years.
